ISEKI PVH1-TE18 Tobacco Transplanter
MOQ: 1 Piece
Note: If you have any questions,please contact us
- High efficiency engine.
- More seedlings can be installed, saving manpower.
- Large planting mouth, adapted to the size of tobacco seedlings.
- Can carry out high-precision transplanting operations.
- Excellent field adaptability.
- PVH1-TE18
Dongfeng Iseki Agricultural Machinery Co., Ltd
Since:
2014
You May Also Like
Product Description
ISEKI PVH1-TE18 Tobacco Transplanter
1.High efficiency engine
High-efficiency engine to ensure transplanting efficiency.
Equipped with high-horsepower air-cooled gasoline engine, low-vibration, low-noise design, easy and comfortable operation, transplanting efficiency of 2,300 plants/hour, about 4.6 times that of manual labor.
2.More seedlings can be installed, saving manpower
It adopts a large, widened, rotatable and foldable auxiliary seedling stand, which can carry a large number of tobacco seedlings and can be retracted when encountering obstacles.
3.Large planting mouth, adapted to the size of tobacco seedlings
The large interpolating mouth adapts to the size of the tobacco seedlings.
The special seedling cup adopts a large tobacco duckbill, which can smoothly interpolate even the large tobacco seedlings. It uses a horizontally opened interpolation mouth without seedlings; adopts a large tobacco seedling cup .
4.Can carry out high-precision transplanting operations
Left and right horizontal device, body lift sensor.
The left and right horizontal device can easily adjust the body tilt by adjusting the handle, and it can be transplanted neatly even on uneven land on the left and right;
The body lift sensor can adapt to the unevenness of the ridge, automatically lift, and keep the transplant depth consistent;
5.Excellent field adaptability
Jingguan Tobacco Transplanting Machine is specially tailored for China's tobacco cultivation system.
6.Main technical parameters
| Product Model | 2ZY-1A (PVH1-TE18) | |||
| Machine Size | L * W * H | (mm) | 2000*1170*1010 | |
| Machine weight | (kg) | 167 | ||
| Engine | Model/Species | / | FJ100G /Air-cooled 4 stroke OHV gasoline engine | |
| Power/Turning speed | (kw/rpm) | 1.5/1700 | ||
| Travel unit | Tread adjustment | (mm) | 800-1180 | |
| Tilt angle | (°) | Left/Right 5 | ||
| Operating speed | （m/s） | 0.18-0.50 | ||
| Interpolation section | Line number of interpolation | (line) | 1 | |
| Depth of interpolation | (cm) | 16~22 (9 Gear) | 10-16 (9 Gear) | |
| Distance of interpolation | (cm) | 48.50.52.55.57.60.63.65.68 (9 Gears) | ||
| Working efficiency | (plant/hour) | 2300 (According to the field condition) | ||
