Français- Removing the Old Pump
Step 1
Located the power steering pump on the driver's side of the engine compartment. Loosen the bolts and remove the engine drive belt.
Step 2
Remove the bolts and the power steering pump pulley.
Step 3
Loosen the clamp and disconnect the return hose from the power steering pump.
Step 4
Drain the power steering fluid into a suitable 1-quart container.
Step 5
Remove the bolt from the pressure line bracket and disconnect the pressure line from the engine.
Step 6
Loosen the power steering pump bolts.
Step 7
Disconnect the pressure line from the pump. Remove and discard the O-ring seal.
Remove the bolts and the power steering pump.
- Installing the New Pump
Step 1
Position the new power steering pump in the engine. Install and tighten the bolts.
Step 2
Install a new O-ring seal on the pressure line, using the O-ring tool.
Step 3
Reconnect the pressure line to the pump. Tighten the power steering pump bolts and reattach the pressure line to the engine. Reattach the pressure line bracket bolt.
Step 4
Reattach the clamp and the return hose to the pump.
Step 5
Reinstall the pulley and the engine drive belt and tighten the bolts.
Fill the power steering system with fluid.(Turn the steering wheel all the way to the left and right several times. Add fluid as needed. Turn the steering wheel all the way to the left and right several more times. Add more fluid, if needed. Repeat until the fluid level stabilizes.)
