Wheeled Tractor Crown A Series CFA450
MOQ: 1 PCS
Note: If you have any questions,please contact us
- 1.Utilized in plowing, rotary tillage and transportation.
- 2.Strong power, high ground clearance.
- 3.Adjustable wheel track.
- 4.New type fuel filter
- 5.Optional device: Belt driving power take-off device.
- CFA450
Jiangsu Changfa Agricultural Equipment Holding Co.,Ltd
Since:
2003
Product Description
1. Changfa Crown A series tractor (horsepower ranging from 25 to 50) adopts 9F plus 3R side shift.
2. New design, Luxury model with beautiful appearance and works perfectly in both muddy field and dry land, meeting the demand of ploughing, rotary tilling and transporting work.
3. Large volume rotational tank gives long time running, Safety Frame, Sunshade and Drivers Cab
| project | unit | CFA450 |
| engine model | / | CF4B45T |
| Engine type | / | Three-cylinder, vertical train, water-cooled, four-stroke, direct injection |
| Engine nominal power | kw | 33.1 |
| Calibration speed | r/min | 2400 |
| Dimensions (L*W*H) | mm | 3580*1491*2070 |
| Wheelbase | mm | 1815 |
| Wheel base (front wheel) | mm | 1010-1210 (1010), optional 1150-1450 (usually 1250) |
| Wheel base (rear wheel) | mm | Step adjustment: 1035-1406 (commonly used 1200), optional narrow stepless adjustment 1000: 1000-1506 (commonly used 1024), common wheelbase stepless adjustment: 1214-1542 (commonly used 1214) |
| Minimum ground clearance | mm | 335 |
| Calibration traction | mm | 6.5 |
| Tire specifications (front wheel) | / | 5.00-15 |
| Tire specifications (rear wheel) | / | 9.5-24 |
| Minimum use quality | kg | 1500 |
| clutch | / | Dry type, single piece, often combined, single action |
| Gearbox | / | 9 forward gears + 3 reverse gears, sliding gear shift |
| Brake type | / | Dry type, hoof type |
| Driving speed | km/h | A500: forward 2.26-30.38, backward 3.48-13.93; A400/450 forward 2.17-29.14, backward 3.34-13.37 |
| Maximum lifting force at 610mm behind the lower suspension point | kn | ≥8.5 |
| PTO shaft speed | r/min | 540,760 |
