MD Series Tractor Chassis Structure Adopts A Straight Barrel Shape And Compact
MD Series Tractor Chassis Structure Adopts A Straight Barrel Shape And Compact
MD Series Tractor Chassis Structure Adopts A Straight Barrel Shape And Compact
MD Series Tractor Chassis Structure Adopts A Straight Barrel Shape And Compact
MD Series Tractor Chassis Structure Adopts A Straight Barrel Shape And Compact
MD Series Tractor Chassis Structure Adopts A Straight Barrel Shape And Compact
1 / 4

MD Series Tractor Chassis Structure Adopts A Straight Barrel Shape And Compact

Score
Sold: 0 Question And Answer 0

MOQ: 1 PCS

Note: If you have any questions,please contact us

  • 1. Equipped with synchronization shift gearbox
  • 2. developed with AVL company
  • 3.Stable and reliable four-wheel drive clutch ensures traffic-ability on complex fields.
  • 4. The innovative shift synchronizer makes shifting light and convenient;
  • 5. 16 + 8 (optional creeper gear 24+12), multi-level gear, wide speed range, the tractor can meet the demands of both the low-speed farmland operation and the high-speed road transportation;
  • Euro II MD704
Shandong Wuzheng Group Co. Ltd

Shandong Wuzheng Group Co. Ltd

Since:

1961

You May Also Like

    Product Description

    1. Chassis structure adopts a straight barrel shape and compact, strong and reliable structure. The chasis adopts synchronizer shift technology, shift is convenient and comfortable; The gear type is 16F+8R with different speed to choose (1.84~38.26km/h). Creeper gear is available and gear can be up to 24F+12R, and minimum velocity is 0.27km/h.

    2. Synchronous power output can meet the precise operation demand;

    3.Active pressure lubrication prolongs the service life of key parts, and reduces maintenance costs.

    4.The advantages of compact structure, short wheelbase, small turning radius and flexible steering make the tractor more suitable for the operation on small plot.



    ModelMD704
    Dimensions (L × W× H)mm3880×1935×2600
    Min. operating weightkg2600
    Wheelbasemm2060
    Wheel track (front/rear)mm1280/1380、1400
    Minimum ground clearancemm390
    Minimum turning radiusm4.2±0.5









    Engine

    Model/4G33TC
    Type/In-line, water-cooing, four stroke, DI, naturally aspirated
    Qty of cylindersCylinder4
    Rated powerKW51.5
    Rated speedr/min2300





    Drive train

    Clutch/Dry, independent operation double acting
    Gearbox/

    (2+1)×4×2

    space triaxial combo

    Gear shift type/Synchronizer shift
    SteeringSteering type/Hydraulic steering
    BrakeBrake type/Mechanically operated, wet, disc
    Walking deviceTire size(front/rear)/8.30-24、11.2-20/11.00-32 、14.9-28



    Working device

    Suspension device type/Rear, three-point suspension
    Suspension device category/Category Ⅰ
    Tillage Depth Adjustment/Comprehensive adjustment
    Hydraulic output device/Multi-way valve output
    Standard PTO speedr/min540/1000
